APPLICATION |
| It is suitable for ships and land, in the circuit with AC50 or 60Hz, rated insulation voltage 660V, DC voltage 250V or less, rated current from 3A to 1200A. Used as making and breaking circuit infrequently, and protecting circuit against overload and short circuit. |
| SPECIFICATION |
|
600Type600 |
Pole |
Breaking capacity |
Rated current(A) |
Rated voltage(V) |
|
EA32 |
2 |
1.5KA |
3,5,10,15,20,30 |
415 |
|
EA33 |
3 |
1.5KA |
3,5,10,15,20,30 |
415 |
|
EA52 |
2 |
2.5KA |
15,20,30,40,50 |
600 |
|
EA53 |
3 |
2.5KA |
15,20,30,40,50 |
600 |
|
EA62 |
2 |
2.5KA |
60 |
600 |
|
EA63 |
3 |
2.5KA |
60 |
600 |
|
EA102 |
2 |
7.5KA |
60,75,100 |
600 |
|
EA103 |
3 |
7.5KA |
60,75,100 |
600 |
|
EA202 |
2 |
10KA |
125,150,175,200,225 |
600 |
|
EA203 |
3 |
10KA |
125,150,175,200,225 |
600 |
|
EA402 |
2 |
18KA |
250,300,350,400 |
600 |
|
EA403 |
3 |
18KA |
250,300,350,400 |
600 |
|
EA603 |
3 |
30KA |
500,600 |
600 |
|
EA803 |
3 |
30KA |
500,600 |
600 |
|
660600Type600660 |
Pole |
Breaking capacity |
Rated current(A) |
Rated voltage(V) |
|
SA32 |
2 |
1.5KA |
3,5,10,15,20,30 |
660 |
|
SA33 |
3 |
1.5KA |
3,5,10,15,20,30 |
660 |
|
SA52 |
2 |
5KA |
15,20,30,40,50 |
660 |
|
SA53 |
3 |
5KA |
15,20,30,40,50 |
660 |
|
SA62 |
2 |
5KA |
60 |
660 |
|
SA63 |
3 |
5KA |
60 |
660 |
|
SA102 |
2 |
15KA |
15,20,30,40,50,60,75,100 |
660 |
|
SA103 |
3 |
15KA |
15,20,30,40,50,60,75,100 |
660 |
|
SA202 |
2 |
18KA |
125,150,175,200,225 |
660 |
|
SA203 |
3 |
18KA |
125,150,175,200,225 |
660 |
|
SA402 |
2 |
22KA |
250,300,350,400 |
660 |
|
SA403 |
3 |
22KA |
250,300,350,400 |
660 |
|
SA603H |
3 |
35KA |
500,600 |
660 |
|
SA603L |
3 |
35KA |
500,600 |
660 |
|
SA803H |
3 |
55KA |
700,800 |
660 |
|
SA803L |
3 |
55KA |
700,800 |
660 |
|
SA1003 |
3 |
75KA |
1000 |
660 |
|
SA1203 |
3 |
80KA |
1000 |
660 | | | | |
