The design on the base of the current-limiting device increases the capability of circuit breaking, with a max. Of 7.5KA(AC 220V standard)
The super-miniature and light product leaves the installation area minimum
The over current protection of bimetal sheet and the instantaneous and short-circuit protection featuring solenoid trip produces a perfect protection to current fault.
The assembly mode of DIN-Rail makes the installation easier.
Delicate appearance of Europe-style
Available to fit such accessories as auxiliary switch (AX) and alarm switch, etc. |
| SPECIFICATION |
|
Series |
KBKM |
|
Type |
B |
C |
G |
|
Poles |
1 2 3 |
1 2 3 4 |
1 2 3 |
|
Rated voltage(V) |
240/415 |
|
Rated current(A) |
6,10,16,20,25 |
2,4,6,10,20,25,32,40,50 |
6,10,20,25,32,40,50 |
|
Breaking capacity(KA) |
10 |
6 |
6 |
|
Tripping device |
Thermal-coil magnetic | |
|
Auxiliary switch & alarm switch |
|
|
Rated operational current |
220V 3.5A |
|
AC 11 duty |
415V 2A |
|
Mechanical life |
2000 operations |
|
Thermal capacity |
0.75, 2.5mm |
|
Wtight |
0.04kg/EA | |
 | |
